Dual System Intelligent Conference Tablet Teaching Flat Electronic Blackboard Touch Screen Integrated Machine
1. Infrared touch technology, dual system intelligent teaching / conference tablet integrated machine
2. Whiteboard writing, intelligent annotation, remote conference, multiple functions
3. Industrial control board, high performance, lasting power
4. ISP ultra high definition hard screen, clear picture, good viewing effect, ultra-thin explosion-proof tempered glass, protect touch screen, durable
5. Set computer, broadcast box, projector, projection screen, electronic whiteboard multi-function and one
6. With 10 touch, multiple people can write interactively on the touch screen, breaking the traditional teaching, and cultivating students' interest in interactive teaching,
7. Supporting pictures Word.PPT , PDF and other wireless on the same screen, providing multiple external interfaces to meet the needs
8. Super sensitive touch screen, electronic whiteboard writing, annotation fluent, zoom in, zoom out, move, wipe and other operations do not jam
9. Remote conference, multi screen interaction, remote office screen synchronization, low delay two-phase communication
10. Built in WiFi, stable processor, optional SSD, HD screen, support customization
| Display Information |
| Screen Size | 55inch | 65inch | 75inch | 86inch |
| Panel Type | a-Si TFT-LCD | a-Si TFT-LCD | a-Si TFT-LCD | a-Si TFT-LCD |
| Aspect Ratio | 16:9 | 16:9 | 16:9 | 16:9 |
| Resolution | 3840*2160P | 3840*2160P | 3840*2160P | 3840*2160P |
| Viewing Angle | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 |
| Brightness | 320cd/m2 | 350cd/m2 | 350cd/m2 | 350cd/m2 |
| Active Area | 1209.6x 680.4mm | 1428.48x803.52mm | 1649.664x927.936mm | 1913x1084mm |
| Contrast Ratio | 4000:1 | 4000:1 | 1200:1 | 1200:1 |
| Response Time | 8ms | 8ms | 8ms | 8ms |
| Display Color | 8 bit 1.67M | 8 bit 1.67M | 10 bit 1.07B | 10 bit 1.07B |
| Field Frequency | 60Hz | 60Hz | 60Hz | 60Hz |
| Service Lifetime | ≥60,000 hours | ≥60,000 hours | ≥60,000 hours | ≥60,000 hours |
| Touch System |
| Sensing Type | Infrared System (Multi 10 point touch) |
| Response Time | 6ms |
| Connection | Full-speed USB (Driver free) |
| Surface Protection | Tempered Glass with 4mm thickness Standard |
| Graphic card | Intel HD Graphics, Supports 1080P, H264, 3D play |
| Bluetooth | Bluetooth4.0 |
| Speaker | 15W x2 |
| Network | WIFI/ RJ45 |
| Port | USB2.0*2/ USB3.0*2/ HDMI out*1/ VGA out*1/ RJ45 Lan port*1/ Speaker out*1/ Mic in*1 |
| Built-in Dual System Android and Windows |
| Operating System | Android 6.0 |
| CPU | Quad Core Cortex A7 1.8 GHZ |
| RAM | DDR3 2G |
| ROM | 32G |
| SD card slot | Support MAX 128G |
| Port | RJ45*1, VGA OUT*1, VGA IN*1, VGA AUDIO IN*1, Ypbpr IN*1, AV IN*2, AV OUT*1, Earphone*1, TV*1, Spdif OUT*1, HDMI IN*2, USB2.0*2, SD card slot*1, Touch USB*2, MIC*1 |
| Languages | English, French, Germany, Arabic, Italian, Japanese,Korean, Russian, Spanish, etc |
| Power |
| Power Supply | 96~264V AC, 50/60Hz |
| Power Consumption | 220W~500W |
| Operating Temperature | 0℃~50℃ |
| Storage Temperature | -10℃~70℃ |
| Supplied Accessories | AC Power Cable, 4-in-1 Remote Control, Touch Pens*2, whiteboard software |
| Ambient Conditions |
| Dimension (L*W*H) | 1290.5*817.6*99.3mm | 1516.3*947.1*96mm | 1737.7*1072.6*103mm | 1991.1x1212.6x125.6mm |
| Package L*W*H | 1427*963*232mm | 1646*1062*230mm | 1860*1230*260mm | 2136*1370x280mm |
| Net weight | 40KG | 50KG | 68KG | 76KG |
